KVInsul-XP

KVINSUL XP is a Carbon Neutral product widely used in steel production/ Foundries as Thermal insulation covering compound. KVINSUL XP is a free flowing, nonhazardous RADEX powder made from Rice Husk Ash as main source of silica and other ingredients. It also known as a Ladle / Tundish covering compound.
Qulity Assurance
Chemical composition & physical properties are maintained and tested according to industry standards

Application:

KVINSUL XP is being speeded over molten metral which is usually at temperature of 1650 o C while in Ladle. It will create a thick layer of about 1’- 2’over molten metal and helps maintaining temperature while being molten metal is being transferred from ladle to tundish. It will prevent the possible breakdown of caster which usually occurs due to drop in temperature.

Packing:

10 / 25 KG PP Bags (standard) 1000 KG Jumbo Bag Chemical composition & physical properties are maintained and tested according to industry standards

Benefits

  • Prevents Heat loss
  • Absorbs nonmetal Impurities
  • Better Metal Quality
  • Prevents Re Oxidation of Metal

Specifications

Chemical Analysis (Mass in %)
  • SiO2 (%)
    86-90%
  • Loss of Ignition
    03-05%
  • Carbon
    03% max
  • H2O
    1.50-02%

Physical Analysis
  • Bulk Density (kg/m3)
    0.250-0.450
  • Sieve Analysis
  • < 0.100mm
    40-45%
  • 0.100 to 0.500mm
    50-58%
  • 0.500 to 02.00mm
    02-05%
  • > 02.00mm
    00%
  • Insulation
    10kW/m2 max
  • Melting point
    > 1500°C
